  1. S15 Engine in S13

    You legend! haha thats way more than I could find. I'll keep trying over the next few day/weeks haha not sure how long it'll take or if I'll even be able to do it. Still looks fairly complicated! I might have to get some friends to have a look and see if they can help too
  2. S15 Engine in S13

    Excellent! Thank you! I'll have a look tomorrow and see if I can compare my wiring to what you've posted and get the thing running
  3. S15 Engine in S13

    Okay awesome Pics and information would be amazing! I'll wait before I attempt anything, so I don't screw anything up. Looking forward to hearing from you!
  4. S15 Engine in S13

    Awesome, thank you Well getting it running is first priority, obviously. Any idea what wires they are that need to be run to near the air box? And where they need to join to? I've been searching for hours :'(
  5. S15 Engine in S13

    Hey everyone! I'm only new to the forum, signed up because I'm well and truly stuck. I've searched online for hours or multiple forums to no avail, so I'm hoping some Silvia guru can help! I've dropped a S15 SR20DET into my S13. Everything is bolted up, just need to make some new intercooler pipes to fit. My issue is with the wiring. I'm completely clueless; no idea where to start. I have the S15 ECU and wiring loom, so the engine side of the wiring is done, easy. It's the wiring to the S13 dash that has me stuck. I can't even find any sort of diagrams to help me. There doesn't seem to be much info out there regarding S15 engine's in S13's. However, the guy I bought this S15 engine from had it running perfectly (dash and air con, etc included) in his S13. Unfortunately he isn't very available to get information from. Obviously, a step by step walk through would be amazing hahaha But I understand people wouldn't have time to do that for me. So any help would be useful! Advice, pictures, links, anything! I will post pictures of the build when it's finished I'll also gladly post any additional information or images if needed, just ask. Thanks again in advance! I've heard a lot of good things about this forum
  6. Bee*R S13 Issue

    But no boost builds up without load on the engine, right? That's where the Bee*R limiter for launching comes in
  7. Bee*R S13 Issue

    At first I was planning to have the Bee*R set to 6500 or 7000RPM, as power dips off after that. But after reading all the issues with SR's, I decided to only use the Bee*R for launch control, surely it can't be that dangerous at 4500rpm? One less avenue of escape is a good thing in my books lol
  8. Bee*R S13 Issue

    From what I can tell, Rocker Arm Stoppers are a necessity if someone wishes to have a Bee*R limiter on their SR. They're a preventative part, preventing lifters from floating. Floating lifters can be snapped and/or bent by the cam's if they happen to float up at the wrong time. Bee*R is known to cause the lifters to float on SR's, hence why a rocker arm stopper is important However, they can also have lifters 'catch' on them, causing the lifter to break, but that is almost always only caused by over-revving. And even then, the rocker arm stoppers should help lessen any damage caused, by preventing broken lifters from floating around the head, destroying more parts. Well, at least this is the information I've gathered from my last hour of research
  9. Bee*R S13 Issue

    How do rocker arm stopper's do more damage than good?
  10. Bee*R S13 Issue

    Yeah, I'm thinking it might be the actual unit too :/ I bought it new, so I'll just look into getting a replacement.
